Assembled Panel

Physical Analog

Reference devices: Camera Viewfinder HUD, Audio Mixer Strip, complete equipment front panels. Mechanism: An assembled panel is not a single component but a composition of multiple pudge-ui components within a Panel container (I1). This document describes the composition rules and patterns for building complex, multi-component panels that maintain physical plausibility.

Geometry

CSS Recipe

Assembled panels use the base .panel CSS from I1, combined with layout utilities:

Panel container

.panel {
  position: relative;
  background: linear-gradient(180deg, var(--bg-surface), var(--bg-panel));
  border: 1px solid var(--border-mid); border-radius: var(--radius-lg);
  padding: 22px;
  box-shadow: 0 2px 0 var(--border-deep), 0 10px 28px rgba(0,0,0,0.3), inset 0 1px 0 var(--border-hi);
  overflow: hidden;
}

Layout helpers

.flex-row { display: flex; gap: 12px; align-items: flex-end; flex-wrap: wrap; }
.flex-col { display: flex; flex-direction: column; gap: 8px; }

Serial / fabrication block

.serial { margin-top: 16px; color: var(--text-muted); font-size: 9px; letter-spacing: 2px; display: flex; justify-content: space-between; font-family: var(--font-ui); }

HTML Structure

Example: Diagnostic Panel

<div class="panel" style="width:360px">
  <div class="panel-title">SYSTEM DIAGNOSTICS</div>

  <!-- Status bar at top -->
  <div class="status-bar" style="margin-bottom:14px">
    <span class="sb-time">14:32</span>
    <div class="sb-icons">
      <div class="led-dot green"></div>
    </div>
  </div>

  <!-- Mode indicator -->
  <div class="flex-row" style="gap:8px;margin-bottom:14px">
    <div class="mode-badge">
      <span class="mode-letter">M</span>
      <div class="mode-detail"><span class="mode-key">MODE</span><span class="mode-sub">Manual</span></div>
    </div>
    <div class="chip-row">
      <div class="status-chip active">ONLINE</div>
      <div class="status-chip">REMOTE</div>
    </div>
  </div>

  <!-- Data readout -->
  <table class="data-table" style="margin-bottom:14px">
    <thead><tr><th>PARAM</th><th>VALUE</th><th>STATUS</th></tr></thead>
    <tbody>
      <tr><td>CPU</td><td class="val">72C</td><td><div class="led-dot green"></div></td></tr>
      <tr><td>MEM</td><td class="val">8.2G</td><td><div class="led-dot green"></div></td></tr>
    </tbody>
  </table>

  <!-- Controls -->
  <div class="flex-row" style="gap:8px">
    <button class="push-btn xs active">MODE</button>
    <button class="push-btn xs">RESET</button>
    <button class="push-btn xs">CONFIG</button>
  </div>

  <div class="serial"><span>REV-C</span><span>UNIT-07</span></div>
</div>

Size Variants

No size variants defined. Assembled panels scale to content and container.

Material Variants

Assembled panels can combine multiple materials following the 2-material rule:

• Panel body: brushed metal or glossy polycarbonate
• Controls within: rubber buttons, glossy buttons, phosphor displays
• Maximum 2 materials per panel for physical plausibility

Theme Behavior

• All sub-components follow their individual theme rules
• Panel container follows I1 Panel theme behavior
• Consistent lighting direction must be maintained (all gradients top-to-bottom)

Constraints

Composition Rules (from design.md)

1. Hierarchy: The panel container (I1) provides the outer frame. Content is organized in rows/columns within.
2. Spacing: Use --space-md (14px) for gaps between related components, --space-lg (22px) for gaps between groups.
3. Consistent lighting: All components in a panel share the same light direction (top-left). MUST NOT mix components with different gradient directions.
4. Status bar placement: Status information (status bar, mode badges, battery) goes at the TOP edge. Controls go in the MIDDLE. Metadata (serial numbers, timecodes) goes at the BOTTOM.
5. Material consistency: Within a single panel, use at most 2 materials (e.g., brushed metal knobs on a rubber panel surface). Too many materials in one panel breaks physical plausibility.
6. MUST include serial/revision block at the bottom (manufacturing authenticity detail).
7. MUST use .panel-title with --font-display for the panel name.
8. MUST use .panel-label for section dividers within the panel.

Accessibility

• Assembled panel should use role="region" with aria-label describing the panel purpose
• Internal sections should use appropriate heading levels
• Tab order within the panel should follow visual top-to-bottom, left-to-right order
• All sub-component accessibility rules apply individually
• Complex panels may benefit from aria-describedby pointing to a usage description
