Using pudge-ui with Coding Agents

This guide explains how to feed pudge-ui design specs to any LLM or coding agent to generate 2000s-inspired UI components in any framework.

Core Principle

pudge-ui is not code — it is context. You feed the spec to your coding agent, describe what you want, and the agent generates components in your framework (React Native, SwiftUI, Jetpack Compose, Flutter, web CSS, etc.).

What to provide

Every request to your agent needs two layers of context:

1. Foundation (always include)

The foundation establishes the design system's rules. Without it, the agent will make incorrect visual decisions. Include these files:

File What it provides Size
philosophy.md Core design principles (physical analog, warm neutrals, 3-plane depth) ~1.5KB
tokens.md All color, spacing, typography, radius, motion, shadow values ~6KB
materials.md 6 material recipes with full CSS ~4KB
depth-model.md Shadow stack rules, press interaction, glow effects ~4KB
naming.md Class naming conventions ~1KB

Total foundation: ~17KB. This fits easily within any LLM's context window.

2. Component specs (include only what you need)

Each component has its own spec file (~2-5KB each). Include only the components you're building. Each file contains:

  • The physical analog (what real hardware it mimics)
  • Exact CSS recipe (copy-paste ready)
  • HTML structure
  • Size/material/state variants
  • Constraints (rules that prevent "close but wrong" implementations)

How to prompt

Pattern 1: Generate a single component

Here is the pudge-ui design system foundation:
[paste foundation files]

Here is the component spec:
[paste component spec file]

Generate this component in [React Native / SwiftUI / Jetpack Compose / Flutter].
Follow the CSS recipe exactly — translate each CSS property to the framework equivalent.
Follow the Constraints section strictly.

Pattern 2: Build a screen with multiple components

Here is the pudge-ui design system foundation:
[paste foundation files]

Here are the component specs I need:
[paste 3-5 component spec files]

Build a [music player / camera viewfinder / settings screen] using these components.
Arrange them according to the composition rules in the foundation.

Pattern 3: Create a new component (not in the spec)

Here is the pudge-ui design system foundation:
[paste foundation files]

Here is an example component spec for reference:
[paste one component spec as an example]

Here is the extension guide:
[paste extension.md]

Create a new component: [describe what you need].
Follow the extension guide's checklist. Choose a physical 2000s-era analog.
Use the foundation's material recipes and depth model.

Using the MCP server

If your agent supports MCP (Claude Code, Cursor, etc.), install the pudge-ui MCP server for automatic context delivery:

{
  "mcpServers": {
    "pudge-ui": {
      "command": "npx",
      "args": ["@pudge-ui/mcp-server"]
    }
  }
}

The agent can then call:

  • get_component("push-button") — returns foundation + component spec
  • get_components(["push-button", "toggle-switch"]) — returns foundation + multiple specs
  • list_components() — browse the catalog
  • search_components("dial") — fuzzy search

Framework translation guide

When translating CSS to native frameworks, map these properties:

CSS Property React Native SwiftUI Jetpack Compose
background: linear-gradient(...) LinearGradient component LinearGradient Brush.linearGradient(...)
box-shadow: 0 2px 0 #color elevation + shadowColor/Offset/Radius .shadow(color:radius:x:y:) Modifier.shadow(elevation, color)
box-shadow: inset ... Inner View with gradient overlay overlay with gradient drawBehind with gradient
border-radius borderRadius .cornerRadius() shape = RoundedCornerShape()
transform: translateY(1px) Animated.Value .offset(y:) with animation Modifier.offset(y = 1.dp)
transition: 70ms ease Animated.timing({ duration: 70 }) .animation(.easeOut(duration: 0.07)) animateFloatAsState(animationSpec = tween(70))
backdrop-filter: blur(4px) BlurView library .ultraThinMaterial Not natively supported — use RenderEffect.createBlurEffect

Critical rules for agents

  1. Always include foundation context. A component spec without the foundation will produce incorrect shadows, wrong colors, and missing materials.

  2. Follow the Constraints section literally. The constraints exist for physical accuracy. "Travel MUST be 1-2px" means exactly that — not 3px, not 5px.

  3. Use warm grays, not pure grays. The token #1c1a18 is NOT #1c1c1c. The warmth is the difference between "generic dark UI" and "physical hardware under tungsten lighting."

  4. The 3-plane shadow model is non-negotiable. Every raised element needs: bottom edge shadow + inner top highlight + inner bottom shadow. Omitting any layer breaks the physical illusion.

  5. Glow effects simulate light emission. LEDs glow, phosphor screens glow, active indicators glow. Use box-shadow with the accent glow color, not just a color change.

  6. Materials are recipes, not suggestions. Each material (rubber, glossy, metal, etc.) has a specific gradient, border, and shadow recipe. Don't mix properties between materials.

Feed foundation + component spec to your agent. It handles the rest.
